    Expansion Joint 4-1/2" Expansion Joint Non-Splined For Well Completion

    Ask Lasest Price
    Brand Name : ZZ TOP OIL TOOLS
    Model Number : 4 1/2" Expansion Joint
    Certification : ISO, API
    Price : USD 1-10000/set
    Payment Terms : L/C, T/T, D/P
    Supply Ability : 10 set/month
    Delivery Time : 30-50 days
    • Product Details
    • Company Profile

    Expansion Joint 4-1/2" Expansion Joint Non-Splined For Well Completion

    Expansion Joint 4-1/2" Expansion Joint Non-Splined For Well Completion


    The Expansion Joint is designed for use above packers in well completions to compensate for tubing movement during treating and injection
    operations. The Expansion Joint allows tubing elongation and/or contraction for the maximum expansion length of the Expansion Joint. The
    Expansion Joint can be pinned in the open or closed position. It is made up in the tubing string and run into the well with packers and other downhole flow control equipment.

    Specifcation of 4 1/2" Expansion Joint


    Manufacturer Produce NameEXPANSION JOINT
    StandardNACE
    Metallic Material4140L80
    Nonmetallic MaterialHNBR / PTFE / PEEK
    Drift Gauge3.750in
    Minimum uID3.780in
    Gauge OD5.500in
    Overall Length180.00in
    Temperature Range350
    Pressure Rating10,000psi
    Piston Area17.82inch²
    Shear Screw Hole QTY12
    Shear Screw QTY.8
